Category: Hydraulic Hose Pipe
SAE100-R13
Product Description
350 bar super high pressure hydraulic lines and hydrostatic transmission lines
Also, suitable for impulse surge lines with more life cycles
For use with petroleum, synthetic or water based fluids in hydraulic systems
Suitable for earthmoving equipments and machineries / systems
 |
 |
 |
 |
 |
||||||
|---|---|---|---|---|---|---|---|---|---|---|
| DN | HOSE I. D. (NOM.) | HOSE O. D. (NOM.) | WORKING PRESSURE | MIN. BURST PRESSURE | MIN. BEND RADIUS | |||||
| (IN.) | (MM) | (IN.) | (MM) | (PSI) | (BAR) | (PSI) | (BAR) | (MM) | (IN.) | |
| 19 | 3/4 | 19.0 | 1.26 | 32.1 | 5,000 | 345 | 20,000 | 1,380 | 240 | 9.60 |
| 25 | 1 | 25.4 | 1.54 | 39.2 | 5,000 | 345 | 20,000 | 1,380 | 300 | 12.00 |
| 32 | 1.1/4 | 31.8 | 2.00 | 50.8 | 5,000 | 345 | 20,000 | 1,380 | 420 | 16.80 |
| 38 | 1.1/2 | 38.1 | 2.28 | 57.9 | 5,000 | 345 | 20,000 | 1,380 | 500 | 20.00 |
| 50 | 2 | 50.9 | 2.83 | 71.9 | 5,000 | 345 | 20,000 | 1,380 | 640 | 25.60 |
