Category: Hydraulic Hose Pipe
SAE100-R3
Product Description
Low Pressure and low impulse hydraulic lines 30 to 110 bar
For use with petroleum, synthetic or water based fluids in hydraulic systems
Suitable for Agrucultural, Earthmoving & Material Handling equipments and machineries / systems.
 |
 |
 |
 |
 |
||||||
|---|---|---|---|---|---|---|---|---|---|---|
| DN | HOSE I. D. (NOM.) | HOSE O. D. (NOM.) | WORKING PRESSURE | MIN. BURST PRESSURE | MIN. BEND RADIUS | |||||
| (IN.) | (MM) | (IN.) | (MM) | (PSI) | (BAR) | (PSI) | (BAR) | (MM) | (IN.) | |
| 5 | 3/16 | 4.8 | 0.47 | 12.0 | 1,600 | 110 | 6,400 | 440 | 75 | 3.00 |
| 6 | 1/4 | 6.4 | 0.53 | 13.5 | 1,300 | 90 | 5,200 | 360 | 75 | 3.00 |
| 8 | 5/16 | 8.0 | 0.66 | 16.8 | 1,230 | 85 | 4,920 | 340 | 100 | 4.00 |
| 10 | 3/8 | 9.5 | 0.73 | 18.5 | 1,160 | 80 | 4,640 | 320 | 100 | 4.00 |
| 12 | 1/2 | 12.7 | 0.91 | 23.1 | 1,010 | 70 | 4,040 | 280 | 125 | 5.00 |
| 16 | 5/8 | 16.0 | 1.04 | 26.3 | 870 | 60 | 3,480 | 240 | 140 | 5.60 |
| 19 | 3/4 | 19.0 | 1.23 | 31.2 | 800 | 55 | 3,200 | 220 | 150 | 6.00 |
| 25 | 1 | 25.4 | 1.46 | 37.0 | 580 | 40 | 2,320 | 160 | 200 | 8.00 |
| 32 | 1.1/4 | 31.8 | 1.70 | 43.1 | 440 | 30 | 1,760 | 120 | 250 | 10.00 |
